Asus (ESC4000-E10) Intel C621A, 2U Dual-Socket GPU Barebone Server, LGA 4189, Supports 8 GPUs, Dual GB LAN, OCP 3.0, PCIe 4.0, M.2, 2200W Platinum PSU
Asus (ESC4000-E10) Intel C621A, 2U Dual-Socket GPU Barebone Server, LGA 4189, Supports 8 GPUs, Dual GB LAN, OCP 3.0, PCIe 4.0, M.2, 2200W Platinum PSU
2U GPU server powered by dual-socket 3rd Gen Intel Xeon Scalable processors that supports up to 16 DIMM, four dual-slot GPU, 4 M.2, eight NVMe (by SKU), total eleven PCIe 4.0 slots, one OCP 3.0 (by SKU) and ASUS ASMB10-iKVM.
- Powered by dual-socket 3rd Gen Intel Scalable processors, with 16 DIMMs and support for a maximum TDP of up to 205 watts per socket
- GPU-optimised design allows four dual-slot GPUs for AI workloads
- Up to eight all-flash NVMe and eight SATA/SAS drives on front panel to enable extensive storage and high-throughput performance
- Up to eleven PCIe 4.0 slots to enable higher bandwidth and improved data-transfer rates
- Flexible air- solution to achieve lower power-usage effectiveness (PUE) and optimised TCO for data centers
- Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
- High power efficiency with redundant 2200W or 1600W 80 Plus Platinum power supplies
- Two hot-plug, hot-swap fans design for fully redundancy protection and thermal efficiency
3rd Gen Intel Xeon Scalable Processors
The latest 3rd Gen Intel Xeon Scalable Processors feature core counts from 8 to 40 cores and an array of frequency and power supports, and deliver up to 40% better performance compared to the previous generations. With built-in security features, this new platform delivers outstanding performance in security including encryption, authentication and data integrity across the breadth of standards that are prevalent in networking, enterprise and the cloud.
PCIe 4.0 Ready
PCI Express (PCIe) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS ESC4000-E10 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.
GPU and FPGA support
ESC4000-E10 features a powerful GPU architecture that supports up to four double-slot or eight single-slot GPUs* in a 2U chassis, including NVIDIA A100 or Quadro, plus features NVIDIA NVLink Bridge to enable scaling of performance in order to meet the demands of AI and high-performance computing, and to securely run workloads in virtualisation environments.
ESC4000-E10 is also a Xilinx Alveo-qualified server to provide optimised acceleration for workloads across cloud and on-premises data centers, and for hybrid cloud environments in financial computing, machine learning, computational storage, and data search and analytics.
Flexible front panel design
ESC4000-E10 features a flexible front panel design that allows for easy storage and network expansions and upgrades. The design offers easier accessibility of up to eight NVMe SSD drives and an optional choice of OCP 3.0, a M.2 adapter or HBA/RAID card via PCIe 4.0 slot for better performance and lower latency.
Scalable storage design
To effectively manage the storage demands of growing amounts of data, ESC4000-E10 has a dense chassis design that accommodates up to eight 3.5-inch or 2.5-inch drives, including up to eight NVMe SSDs support and one onboard 2280-length M.2 SSD to allow faster data transfer speeds for OS installation.
NVIDIA-qualified server
ESC4000-E10 is a NVIDIA-qualified server system that deliver unprecedented performance at a fraction of the cost, space, and power requirements of traditional CPU-based solutions, from production rendering to scalable visualization systems or HPC, AI, ML, big data analytics, and at the edge deployment options.
OCP 3.0
ASUS ESC4000-E10 servers feature the latest OCP NIC 3.0 card with PCIe 4.0 bandwidth for a faster time-to-market network solution, delivering the speeds of up to 200 Gbps for high bandwidth and low latency. It also features a tool-less, hot-swappable design to simplify installation and serviceability.
Enhanced security
ASUS ESC4000-E10 server integrate PFR FPGA as the platform Root-of-Trust solution for firmware resiliency to prevent from hackers from gaining access to infrastructure. ASUS security solutions are fully compliant with the 2018 National Institute of Standards and Technology (NIST) SP 800 193 specification.
In addition, ESC4000-E10 server also include support Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.
* Both PFR and TPM are options, available on request.
Server-management solution
ASUS ASMB10-iKVM
ASUS ASMB10-iKVM is the latest server-management solution from ASUS, built upon the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The module provides various interfaces to enable out-of-band server management through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish API.
ASUS Control Center
ASUS Control Center (ACC) is a centralised and integrated IT-management platform for monitoring and controlling ASUS servers, workstations and mini PCs. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.
